Planet GS-4210 SERIES User Manual

User’s Manual of GS-4210 Series
No packet loss will occur.
5.5 Auto-Negotiation
The STP ports on the Switch have a built-in "Auto-negotiation". This technology automatically sets the best possible bandwidth
when a connection is established with another network device (usually at Power On or Reset). This is done by detecting the
modes and speeds when both devices are connected. Both 10BASE-T and 100BASE-TX devices can connect with the port in
either half- or full-duplex mode.
If attached device is: 100BASE-TX port will set to:
10Mbps, without auto-negotiation 10Mbps.
10Mbps, with auto-negotiation 10/20Mbps (10BASE-T/full-duplex)
100Mbps, without auto-negotiation 100Mbps
100Mbps, with auto-negotiation 100/200Mbps (100BASE-TX/full-duplex)
347

Planet GS-4210 SERIES Specifications

General

Power Input	100-240VAC, 50/60Hz
Enclosure	Metal
Product Type	Managed Switch
Ports	24 x 10/100/1000BASE-T, 4 x 100/1000BASE-X SFP
MAC Address Table	8K
Jumbo Frame	9K Bytes
Operating Temperature	0°C to 50°C
Storage Temperature	-40°C to 70°C
Humidity	5% to 95% (non-condensing)
Installation	Rack-mountable
Dimensions	440 x 180 x 44 mm (W x D x H)
Weight	GS-4210-24UP4S: 2500g
