User’s Manual of GS-4210 Series

4.14.4 RMON Alarm

Configure RMON Alarm table on this page. The RMON Alarm screens in Figure 4-14-5 & Figure 4-14-6 appear.

Figure 4-14-5: RMON Alarm Table Page Screenshot

The page includes the following fields:

Object Description

 Select Index

Select index for this drop down list to create the new index or modify the index

 Index

Indicates the index of the alarm entry

 Sample Port

Select port for this drop down list

 Sample Variable

Indicates the particular variable to be sampled, the possible variables are:

 DropEvents: The total number of events in which packets were dropped due

to lack of resources.

 Octets: The number of received and transmitted (good and bad) bytes.

Includes FCS, but excludes framing bits.

 Pkts: The total number of frames (bad, broadcast and multicast) received

and transmitted.

 BroadcastPkts: The total number of good frames received that were

directed to the broadcast address. Note that this does not include multicast

packets.

 MulticastPkts: The total number of good frames received that were directed

325
