User’s Manual of GS-4210 Series

Object Description

 Port

This is the logical port number for this row

 Description

Click

to indicate the port name

 Enable State

Display the current port state

 Link Status

Display the current link status

 Speed

Display the current speed status of the port

 Duplex

Display the current duplex status of the port

 Flow Control

Configuration

Display the current flow control configuration of the port

 Flow Control Status

Display the current flow control status of the port

4.3.2 Port Counters

This page provides an overview of traffic and trunk statistics for all switch ports. The Port Statistics screens in Figure 4-3-3,

Figure 4-3-4, Figure 4-3-5 & Figure 4-3-6 appear.

Figure 4-3-3 Port MIB Counters Page Screenshot

The page includes the following fields:

Object Description

 Port

Select port number for this drop down list.

 Mode

Select port counters mode.

Option:

 All

 Interface

 Ether-link

 RMON
