User’s Manual of GS-4210 Series

4.12.5 LLDP Remove Device

This Page provides a status overview for all LLDP remove devices. The displayed table contains a row for each port on which

an LLDP neighbor is detected. The LLDP Remove Device screen in Figure 4-12-9 appears.

Figure 4-12-9 LLDP Remote Device Page Screenshot

The page includes the following fields:

Object Description

 Local Port

Display the current local port

 Chassis ID Subtype

Display the current chassis ID subtype

 Chassis ID

The Chassis ID is the identification of the neighbor's LLDP frames

 Port ID Subtype

Display the current port ID subtype

 Port ID

The Remote Port ID is the identification of the neighbor port

 System Name

System Name is the name advertised by the neighbor unit

 Time to Live

Display the current time to live

Buttons

: Click to delete LLDP remove device entry.

: Click to refresh LLDP remove device.

305
