User’s Manual of GS-4210 Series

Figure 4-8-23 Properites Page Screenshot

The page includes the following fields:

Object Description

 Voice VLAN State

Display the current voice VLAN state.

 Voice VLAN ID

Display the current voice VLAN ID.

 Remark CoS/802.1p

/802.1p. Display the current remark CoS

 1p remark

Display the current 1p remark.

 Aging

Display the current aging time.

4.8.5.3 Telephony OUI MAC Setting

Configure VOICE VLAN OUI table on this Page. The Telephony OUI MAC Setting screens in Figure 4-8-24 & Figure 4-8-25

appear.

Figure 4-8-24 Voice VLAN OUI Settings Page Screenshot

The page includes the following fields:

210
