Planet GS-4210 SERIES User Manual

User’s Manual of GS-4210 Series
4.10.1 MAC-based ACL
This page shows the ACL status by different ACL users. Each row describes the ACE that is defined. It is a conflict if a specific
ACE is not applied to the hardware due to hardware limitations. MAC-based ACL screens in Figure 4-10-1 & Figure 4-10-2
appear.
Figure 4-10-1 MAC-based ACL Page Screenshot
The page includes the following fields:
Object Description
 ACL Name
Create a named MAC-based ACL list
 ACL Table
Figure 4-10-2 ACL Table Page Screenshot
The page includes the following fields:
Object Description
 Delete
Click to delete ACL name entry
274

Planet GS-4210 SERIES Specifications

General

Power Input	100-240VAC, 50/60Hz
Enclosure	Metal
Product Type	Managed Switch
Ports	24 x 10/100/1000BASE-T, 4 x 100/1000BASE-X SFP
MAC Address Table	8K
Jumbo Frame	9K Bytes
Operating Temperature	0°C to 50°C
Storage Temperature	-40°C to 70°C
Humidity	5% to 95% (non-condensing)
Installation	Rack-mountable
Dimensions	440 x 180 x 44 mm (W x D x H)
Weight	GS-4210-24UP4S: 2500g
