User’s Manual of GS-4210 Series

4.11.2 MAC Filtering

By filtering MAC address, the switch can easily filter the per-configured MAC address and reduce the un-safety. The Static MAC

Setting screens in Figure 4-11-3 & Figure 4-11-4 appear.

Figure 4-11-3 MAC Filtering Setting Page Screenshot

The page includes the following fields:

Object Description

 MAC Address

Physical address associated with this interface

 VLAN (1~4096)

Indicates the ID of this particular VLAN

Buttons

: Click to add new MAC filtering setting.

Figure 4-11-4 Statics MAC Status Page Screenshot

The page includes the following fields:

Object Description

 No.

This is the number for entries

 MAC Address

The MAC address for the entry

 VLAN

The VLAN ID for the entry

 Delete

Click to delete static MAC status entry.

293
