User’s Manual of GS-4210 Series

The page includes the following fields:

Object Description

 LAG

The LAG for the settings contained in the same row

 Name

Display the current name

 Type

Display the current type

 Link State

Display the link state

 Active Member

Display the active member

 Standby Member

Display the standby member

 Modify

Click

to modify LAG configuration

4.4.3 LAG Port Setting

This page allows setting configuration for each LAG. The LAG Port Setting screens in Figure 4-4-6 & Figure 4-4-7 appear.

Figure 4-4-6 LAG Port Setting Information Page Screenshot

The page includes the following fields:

Object Description

 LAG Select

Select LAG number for this drop down list.

 Enable

Indicates the LAG state operation. Possible states are:

Enabled - Start up the LAG manually.

Disabled – Shut down the LAG manually.

 Speed

Select any available link speed for the given switch port. Draw the menu bar to

select the mode.

 Auto – Set up Auto negotiation.

 Auto-10M – Set up 10M Auto negotiation.

 Auto-100M – Set up 100M Auto negotiation.

108
