User’s Manual of GS-4210 Series
Auto-1000M - Set up 1000M Auto negotiation.
Auto-10/100M – Set up 10/100M Auto negotiation.
10M – Set up 10M Force mode.
100M – Set up 100M Force mode.
1000M – Set up 1000M Force mode.
Flow Control
When Auto Speed is selected for a port, this section indicates the flow control
capability that is advertised to the link partner. When a fixed-speed setting is
selected, that is what is used. The current Rx column indicates whether pause
frames on the port are obeyed. The current Tx column indicates whether pause
frames on the port are transmitted. The Rx and Tx settings are determined by the
result of the last Auto-Negotiation. Check the configured column to use flow
control. This setting is related to the setting for Configured Link Speed.
Buttons
: Click to apply changes.
Figure 4-4-7 LAG Port Status Page Screenshot
The page includes the following fields:
Object Description
LAG
The LAG for the settings contained in the same row
Description
Display the current description
Port Type
Display the current port type
Enable State
Display the current enable state
Speed
Display the current speed
109
