User’s Manual of GS-4210 Series

Figure 4-7-19 Forbidden Router Table Page Screenshot

The page includes the following fields:

Object Description

 VLAN ID

Display the current VLAN ID

 Port Mask

Display the current port mask

4.7.2.7 IGMP Forward All

This page provides IGMP Forward All. The Forward All screen in Figure 4-7-20 appears.

Figure 4-7-20 Forward All Setting Page Screenshot

The page includes the following fields:

Object Description

 VLAN ID

Select VLAN ID for this drop down list to assign IGMP membership

176
