User’s Manual of GS-4210 Series

4.8.2.2 QoS Port Settings

The QoS Port Settings and Status screen in Figure 4-8-2 & Figure 4-8-3 appear.

Figure 4-8-2 QoS Port Setting Page Screenshot

The page includes the following fields:

Object Description

 Port Select

Select port number for this drop down list

 CoS Value

Select CoS value for this drop down list

 Remark CoS

Disable or enable remark CoS

 Remark DSCP

Disable or enable remark DSCP

 Remark IP Precedence

Disable or enable remark IP Precedence

Buttons

: Click to apply changes.

 QoS Port Status

Figure 4-8-3 QoS Port Status Page Screenshot

196
