User’s Manual of GS-4210 Series
The page includes the following fields:
Object Description
 Port Name
The switch port number of the logical port
 Priority
Display the current LACP priority parameter
 Timeout
Display the current timeout parameter
4.4.6 LAG Status
This page displays LAG status. The LAG Status screens in Figure 4-4-12 & Figure 4-4-13 appear.
Figure 4-4-12 LAG Status Page Screenshot
The page includes the following fields:
Object Description
 LAG
Display the current trunk entry
 Name
Display the current LAG name
 Type
Display the current trunk type
 Link State
Display the current link state
 Active Member
Display the current active member
 Standby Member
Display the current standby member
112

Planet GS-4210 SERIES Specifications

General

Power Input	100-240VAC, 50/60Hz
Enclosure	Metal
Product Type	Managed Switch
Ports	24 x 10/100/1000BASE-T, 4 x 100/1000BASE-X SFP
MAC Address Table	8K
Jumbo Frame	9K Bytes
Operating Temperature	0°C to 50°C
Storage Temperature	-40°C to 70°C
Humidity	5% to 95% (non-condensing)
Installation	Rack-mountable
Dimensions	440 x 180 x 44 mm (W x D x H)
Weight	GS-4210-24UP4S: 2500g
