User’s Manual of GS-4210 Series

4.13.2 Ping

The ping and IPv6 ping allow you to issue ICMP PING packets to troubleshoot IP connectivity issues. The Managed Switch

transmits ICMP packets, and the sequence number and roundtrip time are displayed upon reception of a reply.

4.13.3 Ping Test

This page allows you to issue ICMP PING packets to troubleshoot IP connectivity issues.

After you press “Apply”, ICMP packets are transmitted, and the sequence number and roundtrip time are displayed upon

reception of a reply. The page refreshes automatically until responses to all packets are received, or until a timeout occurs. The

ICMP Ping screen in Figure 4-13-3 appears.

Figure 4-13-3 ICMP Ping Page Screenshot

The page includes the following fields:

Object Description

 IP Address

The destination IP Address

 Count

Number of echo requests to send

 Interval (in sec)

Send interval for each ICMP packet

 Size (in bytes)

The payload size of the ICMP packet. Values range from 8bytes to 5120bytes.

 Ping Results

Display the current ping result.

Buttons

: Click to transmit ICMP packets.

318
