User’s Manual of GS-4210 Series
The page includes the following fields:
Object Description
Server Address
Display the current server address
SNMP Version
Display the current SNMP version
Notify Type
Display the current notify type
Community Name
Display the current community name
UDP Port
Display the current UDP port
Time Out
Display the current time out
Retries
Display the current retry times
Action
: Delete the SNMPv1, 2 host entry.
4.2.7.8 SNMPv3 Notification Recipients
Configure SNMPv3 notification recipients on this page. The SNMPv1, 2 Notification Recipients screens in Figure 4-2-33 &
Figure 4-2-34 appear.
Figure 4-2-33 SNMPv3 Notification Recipients Page Screenshot
The page includes the following fields:
Object Description
Server Address
Indicates the SNMP trap destination address. It allows a valid IP address in
dotted decimal notation ('x.y.z.w'). It can also represent a legally valid IPv4
address. For example, '::192.1.2.34'.
Notify Type
Set the notify type in traps or informs.
User Name
Indicates the user string when send SNMP trap packet.
UDP Port
Indicates the SNMP trap destination port. SNMP Agent will send SNMP message
via this port, the port range is 1~65535.
Time Out
Indicates the SNMP trap inform timeout. The allowed range is 1 to 300.
80
