Planet GS-4210 SERIES User Manual

User’s Manual of GS-4210 Series
4.5.13 GVRP Statistics
The GVRP Port Statistics and Error Statistics screens in Figure 4-5-18 & Figure 4-5-19 appear.
F
igure 4-5-18 GVRP Port Statistics Page Screenshot
The page includes the following fields:
Object Description
 Port
The switch port number of the logical port
 Join Empty (Rx/Tx)
Display the current join empty (TX/RX) packets
 Empty (Rx/Tx)
Display the current empty (TX/RX) packets
 Leave Empty (Rx/Tx)
Display the current leave empty (TX/RX) packets
 Join In (Rx/Tx)
Display the current join in (TX/RX) packets
 Leave In (Rx/Tx)
Display the current leave in (TX/RX) packets
 LeaveAll (Rx/Tx)
Display the current leaveall (TX/RX) packets
F
igure 4-5-19 GVRP Port Error Statistics Page Screenshot
135

Planet GS-4210 SERIES Specifications

General

Power Input	100-240VAC, 50/60Hz
Enclosure	Metal
Product Type	Managed Switch
Ports	24 x 10/100/1000BASE-T, 4 x 100/1000BASE-X SFP
MAC Address Table	8K
Jumbo Frame	9K Bytes
Operating Temperature	0°C to 50°C
Storage Temperature	-40°C to 70°C
Humidity	5% to 95% (non-condensing)
Installation	Rack-mountable
Dimensions	440 x 180 x 44 mm (W x D x H)
Weight	GS-4210-24UP4S: 2500g
