User’s Manual of GS-4210 Series
The page includes the following fields:
Object Description
 Port
The switch port number of the logical port.
 Invalid Protocol ID
Display the current invalid protocol ID
 Invalid Attribute Type
Display the current invalid attribute type
 Invalid Attribute Value
Display the current invalid attribute value
 Invalid Attribute
Length
Display the current invalid attribute length
 Invalid Event
Display the current invalid event.
Buttons
: Click to clear the GVRP Error Statistics.
: Click to refresh the GVRP Error Statistics.
136

Planet GS-4210 SERIES Specifications

General

Power Input	100-240VAC, 50/60Hz
Enclosure	Metal
Product Type	Managed Switch
Ports	24 x 10/100/1000BASE-T, 4 x 100/1000BASE-X SFP
MAC Address Table	8K
Jumbo Frame	9K Bytes
Operating Temperature	0°C to 50°C
Storage Temperature	-40°C to 70°C
Humidity	5% to 95% (non-condensing)
Installation	Rack-mountable
Dimensions	440 x 180 x 44 mm (W x D x H)
Weight	GS-4210-24UP4S: 2500g
