Planet GS-4210 SERIES User Manual

User’s Manual of GS-4210 Series
4.2.7.5 SNMP Community
Configure SNMP Community on this page. The SNMP Community screens in Figure 4-2-27 & Figure 4-2-28 appear.
Figure 4-2-27 Community Setting Page Screenshot
The page includes the following fields:
Object Description
 Community Name
Indicates the community read/write access string to permit access to SNMP
agent.
The allowed string length is 0 to 16.
 Community Mode
Indicates the SNMP community supported mode. Possible versions are:
 Basic: Set SNMP community mode supported version 1 and 2c.
 Advanced: Set SNMP community mode supported version 3.
 Group Name
A string identifying the group name that this entry should belong to.
The allowed string length is 1 to 16.
 View Name
A string identifying the view name that this entry should belong to.
The allowed string length is 1 to 16.
 Access Right
Indicates the SNMP community type operation. Possible types are:
RO=Read-Only: Set access string type in read-only mode.
RW=Read-Write: Set access string type in read-write mode.
Buttons
: Click to apply changes.
Figure 4-2-28 Community Status Page Screenshot
76

Planet GS-4210 SERIES Specifications

General

Power Input	100-240VAC, 50/60Hz
Enclosure	Metal
Product Type	Managed Switch
Ports	24 x 10/100/1000BASE-T, 4 x 100/1000BASE-X SFP
MAC Address Table	8K
Jumbo Frame	9K Bytes
Operating Temperature	0°C to 50°C
Storage Temperature	-40°C to 70°C
Humidity	5% to 95% (non-condensing)
Installation	Rack-mountable
Dimensions	440 x 180 x 44 mm (W x D x H)
Weight	GS-4210-24UP4S: 2500g
