Planet GS-4210 SERIES User Manual

User’s Manual of GS-4210 Series
 Read View Name
Read view name is the name of the view in which you can only view the contents
of the agent.
The allowed string length is 1 to 16.
 Write View Name
Write view name is the name of the view in which you enter data and configure
the contents of the agent.
The allowed string length is 1 to 16.
 Notify View Name
Notify view name is the name of the view in which you specify a notify, inform, or
trap.
Buttons
: Click to add a new access entry.
: Check to delete the entry.
Figure 4-2-26 SNMP View Table Status Page Screenshot
The page includes the following fields:
Object Description
 Group Name
Display the current SNMP access group name
 Security Model
Display the current security model
 Security Level
Display the current security level
 Read View Name
Display the current read view name
 Write View Name
Display the current write view name
 Notify View Name
Display the current notify view name
 Action
: Delete the access group entry.
75

Planet GS-4210 SERIES Specifications

General

Power Input	100-240VAC, 50/60Hz
Enclosure	Metal
Product Type	Managed Switch
Ports	24 x 10/100/1000BASE-T, 4 x 100/1000BASE-X SFP
MAC Address Table	8K
Jumbo Frame	9K Bytes
Operating Temperature	0°C to 50°C
Storage Temperature	-40°C to 70°C
Humidity	5% to 95% (non-condensing)
Installation	Rack-mountable
Dimensions	440 x 180 x 44 mm (W x D x H)
Weight	GS-4210-24UP4S: 2500g
