User’s Manual of GS-4210 Series

 Optional TLVs

If the LLDP MED extended power via MDI packets were sent, or if they were

overloaded

 MED Inventory

Displays if the mandatory group of TLVs was transmitted or overloaded

 802.1 TLVs

Displays if the 802.1 TLVs were transmitted or overloaded

4.12.9 LLDP Statistics

Use the LLDP Device Statistics screen to general statistics for LLDP-capable devices attached to the switch, and for LLDP

protocol messages transmitted or received on all local interfaces. The LLDP Global and Port Statistics screens in Figure 4-12-17

& Figure 4-12-18 appear.

Figure 4-12-17 LLDP Global Statistics Page Screenshot

The page includes the following fields:

Object Description

 Insertions

Shows the number of new entries added since switch reboot.\

 Deletions

Shows the number of new entries deleted since switch reboot.\

 Drops

Shows the number of LLDP frames dropped due to that the entry table was full.\

 Age Outs

Shows the number of entries deleted due to Time-To-Live expiring.\

Buttons

: Click to clear the statistics

: Click to refresh the statistics

314
