User’s Manual of GS-4210 Series

The page includes the following fields:

Object Description

 VLAN ID

Display the current VLAN ID

 Port Mask

Display the current port mask

4.7.4.6 MLD Forward All

This page provides MLD Forward All. The Forward All screen in Figure 4-7-32 appears.

Figure 4-7-32 Forward All Setting Page Screenshot

The page includes the following fields:

Object Description

 VLAN ID

Select VLAN ID for this drop down list to assign MLD membership

 Port

The switch port number of the logical port

Select MLD membership for each interface:

Forbidden:

Interface is forbidden from automatically joining the MLD via MVR.

None:

Interface is not a member of the VLAN. Packets associated with

this VLAN will not be transmitted by the interface.

 Membership

Static:

Interface is a member of the MLD.

185
