User’s Manual of GS-4210 Series

4.8.3.2 Port Settings

The QoS Port Setting and Status screen in Figure 4-8-14 & Figure 4-8-15 appear.

Figure 4-8-14 Basic Mode Global Settings Page Screenshot

The page includes the following fields:

Object Description

 Port

Select port number for this drop down list

 Trust Mode

Enable or disable the trust mode

Buttons

: Click to apply changes.

Figure 4-8-15 QoS Port Status Page Screenshot

The page includes the following fields:

Object Description

 Port

The switch port number of the logical port

 Trust Mode

Display the current trust type

204
