Planet GS-4210 SERIES User Manual

User’s Manual of GS-4210 Series
Buttons
: Click to apply changes.
4.7.5 MLD Snooping Statics
This page provides MLD Snooping Statics. The MLD Snooping Statics screen in Figure 4-7-33 appears.
Figure 4-7-33 Forward All Setting Page Screenshot
The page includes the following fields:
Object Description
 Total RX
Display current total RX
 Valid RX
Display current valid RX
 Invalid RX
Display current invalid RX
 Other RX
Display current other RX
 Leave RX
Display current leave RX
 Report RX
Display current report RX
 General Query RX
Display current general query RX
186

Planet GS-4210 SERIES Specifications

General

Power Input	100-240VAC, 50/60Hz
Enclosure	Metal
Product Type	Managed Switch
Ports	24 x 10/100/1000BASE-T, 4 x 100/1000BASE-X SFP
MAC Address Table	8K
Jumbo Frame	9K Bytes
Operating Temperature	0°C to 50°C
Storage Temperature	-40°C to 70°C
Humidity	5% to 95% (non-condensing)
Installation	Rack-mountable
Dimensions	440 x 180 x 44 mm (W x D x H)
Weight	GS-4210-24UP4S: 2500g
