User’s Manual of GS-4210 Series

4.2.7.7 SNMPv1, 2 Notification Recipients

Configure SNMPv1 and 2 notification recipients on this page. The SNMPv1, 2 Notification Recipients screens in Figure 4-2-31 &

Figure 4-2-32 appear.

Figure 4-2-31 SNMPv1, 2 Notification Recipients Page Screenshot

The page includes the following fields:

Object Description

 Server Address

Indicates the SNMP trap destination address. It allows a valid IP address in

dotted decimal notation ('x.y.z.w'). It can also represent a legally valid IPv4

address. For example, '::192.1.2.34'.

 SNMP Version

Indicates the SNMP trap supported version. Possible versions are:

 SNMP v1: Set SNMP trap supported version 1.

 SNMP v2c: Set SNMP trap supported version 2c.

 Notify Type

Set the notify type in traps or informs.

 Community Name

Indicates the community access string when send SNMP trap packet.

 UDP Port

Indicates the SNMP trap destination port. SNMP Agent will send SNMP message

via this port, the port range is 1~65535.

 Time Out

Indicates the SNMP trap inform timeout. The allowed range is 1 to 300.

 Retries

Indicates the SNMP trap inform retry times. The allowed range is 1 to 255.

Buttons

: Click to add a new SNMPv1, 2 host entry.

Figure 4-2-32 SNMPv1, 2 Host Status Page Screenshot
