User’s Manual of GS-4210 Series
2.1.3 Switch Rear Panel
The rear panel of the Managed Switch indicates an AC inlet power socket, which accepts input power from 100 to 240V AC,
50-60Hz. Figures 2-1-3a~2-1-3d show the rear panel of these Managed Switches
GS-4210-8P2S Rear Panel
Figure 2-1-3a Rear Panel of GS-4210-8P2S
GS-4210-8P2T2S Rear Panel
Figure 2-1-3b Rear Panel of GS-4210-8P2T2S
GS-4210-24P4C Rear Panel
Figure 2-1-3c Rear Panel of GS-4210-24P4C
GS-4210-24PL4C Rear Panel
Figure 2-1-3d Rear Panel of GS-4210-24PL4C
GS-4210-48T4S Rear Panel
Figure 2-1-3e Rear Panel of GS-4210-48T4S
■ AC Power Receptacle
For compatibility with electric service in most areas of the world, the Managed Switch’s power supply automatically adjusts
to line power in the range of 100-240V AC and 50/60 Hz.
33
