User’s Manual of GS-4210 Series

port will be untagged, that is, not carry a tag and therefore not

carry VLAN or CoS information. Note that an interface must be

assigned to at least one group as an untagged port.

 PVID

Display the current PVID

Buttons

: Click to apply changes.

4.5.7 Port VLAN Membership

This page provides an overview of membership status for VLAN users. The VLAN Membership Status screen in Figure 4-5-8

appears.

Figure 4-5-8 Port VLAN Membership Table Page Screenshot

The page includes the following fields:

Object Description

 Port

The switch port number of the logical port

 Mode

Display the current VLAN mode

 Administrative VLANs

Display the current administrative VLANs

 Operational VLANs

Display the current operational VLANs

 Modify

Click

to modify VLAN membership

127
