User’s Manual of GS-4210 Series

4.12.8 LLDP Overloading

The LLDP Port Overloading screen in Figure 4-12-16 appears.

Figure 4-12-16 LLDP Port Overloading Table Page Screenshot

The page includes the following fields:

Object Description

 Interface

The switch port number of the logical port

 Total (Bytes)

Total number of bytes of LLDP information that is normally sent in a packet

 Left to Send (Bytes)

Total number of available bytes that can also send LLDP information in a packet

 Status

Gives the status of the TLVs

 Mandatory TLVs

Displays if the mandatory group of TLVs were transmitted or overloaded

 MED Capabilities

Displays if the capabilities packets were transmitted or overloaded

 MED Location

Displays if the location packets were transmitted or overloaded

 MED Network Policy

Displays if the network policies packets were transmitted or overloaded

 MED Extended Power

via MDI

Displays if the extended power via MDI packets were transmitted or overloaded

 802.3 TLVs

Displays if the 802.3 TLVs were transmitted or overloaded

313
