User’s Manual of GS-4210 Series
1.5 Product Specifications
GS-4210-8P2S / GS-4210-8P2T2S
Product GS-4210-8P2S GS-4210-8P2T2S
Hardware Specifications
Copper Ports
8 x 10/100/1000BASE-T RJ45
Auto-MDI/MDI-X ports
10 x 10/100/1000BASE-T RJ45
Auto-MDI/MDI-X ports
SFP/mini-GBIC Slots
2 x 100/1000BASE-X SFP interfaces with
Port-9 to Port-10.
Supports 100/1000Mbps dual mode and
DDM
2 x 100/1000BASE-X SFP interfaces
with Port-11 to Port-12.
Supports 100/1000Mbps dual mode
and DDM
PoE Injector Port
8 ports with 802.3at / af PoE injector
function with Port-1 to Port-8
8 ports with 802.3at / af PoE injector
function with Port-1 to Port-8
Console ---
1 x RS-232-to-RJ45 serial port (115200,
8, N, 1)
Switch Architecture Store-and-Forward
Switch Fabric 20Gbps / non-blocking 24Gbps / non-blocking
Switch Throughput@64Bytes 14.88Mpps 17.76Mpps
Address Table 8K entries
Shared Data Buffer 4.1 megabits
Flow Control
IEEE 802.3x pause frame for full-duplex
Back pressure for half-duplex
Jumbo Frame
10K bytes
Reset Button
< 5 sec: System reboot
> 5 sec: Factory default
LED
PWR, Fan Alert, LNK/ACT, PoE In-Use,
1000
PWR, SYS, LNK/ACT, PoE In-Use, 1000
Smart Fan
1 1
Dimensions (W x D x H) 330 x 155 x 43.5 mm, 1U high 330 x 200 x 44.5 mm, 1U height
Weight 1687g 2kg
Power Requirements AC 100~240V, 50/60Hz, auto-sensing
ESD Protection 2KV DC 6KV DC
Power Consumption /
Dissipation
165 watts (max.) /
563 BTU
320 watts (max.) /
1091.8 BTU
Enclosure Metal
Power over Ethernet
PoE Standard IEEE 802.3af / 802.3at PoE / PSE
PoE Power Supply Type End-span
PoE Power Output Per Port 52V DC, 36 watts (max.) Per Port 54V DC, 36 watts (max.)
Power Pin Assignment 1/2(+), 3/6(-)
