User’s Manual of GS-4210 Series
4.6.8 STP Statistics
This page displays STP statistics. The STP statistics screen in Figure 4-6-17 appears.
Figure 4-6-17 STP Statistics Page Screenshot
The page includes the following fields:
Object Description
 Port
The switch port number of the logical STP port
 Configuration BPDUs Received
Display the current configuration BPDUs received
 TCN BPDUs Received
Display the current TCN BPDUs received
 MSTP BPDUs Received
Display the current MSTP BPDUs received
 Configuration BPDUs
Transmitted
Display the configuration BPDUs transmitted
 TCN BPDUs Transmitted
Display the current TCN BPDUs transmitted
 MSTP BPDUs Transmitted
Display the current BPDUs transmitted
163

Planet GS-4210 SERIES Specifications

General

Power Input	100-240VAC, 50/60Hz
Enclosure	Metal
Product Type	Managed Switch
Ports	24 x 10/100/1000BASE-T, 4 x 100/1000BASE-X SFP
MAC Address Table	8K
Jumbo Frame	9K Bytes
Operating Temperature	0°C to 50°C
Storage Temperature	-40°C to 70°C
Humidity	5% to 95% (non-condensing)
Installation	Rack-mountable
Dimensions	440 x 180 x 44 mm (W x D x H)
Weight	GS-4210-24UP4S: 2500g
