Planet GS-4210 SERIES User Manual

User’s Manual of GS-4210 Series
4.4.1 LAG Setting
This page allows configuring load balance algorithm configuration settings. The LAG Setting screens in Figure 4-4-2 & Figure
4-4-3 appear.
Figure 4-4-2 LAG Setting Page Screenshot
The page includes the following fields:
Object Description
 Load Balance
Algorithm
Select load balance algorithm mode:
 MAC Address: The MAC address can be used to calculate the port for the
frame.
 IP/MAC Address: The IP and MAC address can be used to calculate the
port for the frame.
Buttons
: Click to apply changes.
Figure 4-4-3 LAG Information Page Screenshot
The page includes the following fields:
Object Description
 Load Balance
Algorithm
Display the current load balance algorithn
106
