User’s Manual of GS-4210 Series
4.7.4.5 MLD Router Table
This page provides Router Table. The Dynamic, Static and Forbidden Router Table screens in Figure 4-7-29, Figure 4-7-30 &
Figure 4-7-31 appear.
Figure 4-7-29 Dynamic Router Table Page Screenshot
The page includes the following fields:
Object Description
VLAN ID
Display the current VLAN ID
Port
Display the current dynamic router ports
Expiry Time (Sec)
Display the current expiry time
Figure 4-7-30 Static Router Table Page Screenshot
The page includes the following fields:
Object Description
VLAN ID
Display the current VLAN ID
Port Mask
Display the current port mask
Figure 4-7-31 Forbidden Router Table Page Screenshot
184
