User’s Manual of GS-4210 Series
Figure 4-5-16 GVRP Port Status Page Screenshot
The page includes the following fields:
Object Description
 Port
The switch port number of the logical port
 Enable Status
Display the current GVRP port state
 Registration Mode
Display the current registration mode
 VLAN Creation Status
Display the current VLAN creation status
4.5.12 GVRP VLAN
The GVRP VLAN Database screen in Figure 4-5-17 appears.
Figure 4-5-17 GVRP VLAN Database Status Page Screenshot
The page includes the following fields:
Object Description
 VLAN ID
Display the current VLAN ID
 Member Ports
Display the current member ports
 Dynamic Ports
Display the current dynamic ports
 VLAN Type
Display the current VLAN type
134

Planet GS-4210 SERIES Specifications

General

Power Input	100-240VAC, 50/60Hz
Enclosure	Metal
Product Type	Managed Switch
Ports	24 x 10/100/1000BASE-T, 4 x 100/1000BASE-X SFP
MAC Address Table	8K
Jumbo Frame	9K Bytes
Operating Temperature	0°C to 50°C
Storage Temperature	-40°C to 70°C
Humidity	5% to 95% (non-condensing)
Installation	Rack-mountable
Dimensions	440 x 180 x 44 mm (W x D x H)
Weight	GS-4210-24UP4S: 2500g
