User’s Manual of GS-4210 Series
The page includes the following fields:
Object Description
LLDP Enable
Display the current LLDP status
LLDP PDU Disable
Action
Display the current LLDP PDU disable action
Transmission Interval
Display the current transmission interval
Holdtime Multiplier
Display the current holdtime multiplier
Reinitialization Delay
Display the current reinitialization delay
Transmit Delay
Display the current transmit delay
LLDP-MED Fast Start
Repeat Count
Display the current LLDP-MED Fast Start Repeat Count
4.12.3 LLDP Port Setting
Use the LLDP Port Setting to specify the message attributes for individual interfaces, including whether messages are
transmitted, received, or both transmitted and received. The LLDP Port Configuration and Status screens in Figure 4-12-3 &
Figure 4-12-4 appear.
Figure 4-12-3 LLDP Port Configuration and Optional TLVs Selection Page Screenshot
The page includes the following fields:
Object Description
Port Select
Select port for this drop down list
State
Enables LLDP messages transmit and receive modes for LLDP Protocol Data
Units. Options:
300
