User’s Manual of GS-4210 Series

4.3.3 Bandwidth Utilization

The Bandwidth Utilization page displays the percentage of the total available bandwidth being used on the ports. Bandwidth

utilization statistics can be viewed using a line graph. The Bandwidth Utilization screen in Figure 4-3-7 appears.

To view the port utilization, click on the Port Management folder and then the Bandwidth Utilization link:

Figure 4-3-7 Port Bandwidth Utilization Page Screenshot

The page includes the following fields:

Object Description

 Refresh Period

This shows the period interval between last and next refresh.

Options:

 2 sec

 5 sec

 10 sec

 IFG

Allow user to enable or disable this function
