Planet GS-4210 SERIES User Manual

User’s Manual of GS-4210 Series
Figure 4-12-8 Port Status Page Screenshot
The page includes the following fields:
Object Description
 Interface
The switch port number of the logical port.
 LLDP Status
Display the current LLDP status
 LLDP MED Status
Display the current LLDP MED Status
304

Planet GS-4210 SERIES Specifications

General

Power Input	100-240VAC, 50/60Hz
Enclosure	Metal
Product Type	Managed Switch
Ports	24 x 10/100/1000BASE-T, 4 x 100/1000BASE-X SFP
MAC Address Table	8K
Jumbo Frame	9K Bytes
Operating Temperature	0°C to 50°C
Storage Temperature	-40°C to 70°C
Humidity	5% to 95% (non-condensing)
Installation	Rack-mountable
Dimensions	440 x 180 x 44 mm (W x D x H)
Weight	GS-4210-24UP4S: 2500g
