User’s Manual of GS-4210 Series

The page includes the following fields:

Object Description

 Port

The switch port number of the logical port

 State

Display the current LLDP status

 Selected Optional

TLVs

Display the current selected optional TLVs

The VLAN Name TLV VLAN Selection and LLDP Port VLAN TLV Status screens in Figure 4-12-5 & Figure 4-12-6 appear.

Figure 4-12-5 VLAN Name TLV Selection Page Screenshot

The page includes the following fields:

Object Description

 Port Select

Select port for this drop down list.

 VLAN Select

Select VLAN for this drop down list.

Buttons

: Click to apply changes.

Figure 4-12-6 LLDP Port VLAN TLV Status Page Screenshot

302
