User’s Manual of GS-4210 Series
Figure 4-2-23 SNMPv3 View Table Setting Page Screenshot
T
he page includes the following fields:
Object Description
 View Name
A string identifying the view name that this entry should belong to.
The allowed string length is 1 to 16.
 Subtree OID
The OID defining the root of the subtree to add to the named view.
The allowed string content is digital number or asterisk (*).
 Subtree OID Mask
The bitmask identifies which positions in the specified object identifier are to be
regarded as "wildcards" for the purpose of pattern-matching.
 View Type
Indicates the view type that this entry should belong to. Possible view type are:
included: An optional flag to indicate that this view subtree should be included.
excluded: An optional flag to indicate that this view subtree should be excluded.
General, if a view entry's view type is 'excluded', it should exist another view
entry in which view type is 'included' and its OID subtree oversteps the 'excluded'
view entry.
Buttons
: Click to add a new view entry.
Figure 4-2-24 SNMP View Table Status Page Screenshot
The page includes the following fields:
73

Planet GS-4210 SERIES Specifications

General

Power Input	100-240VAC, 50/60Hz
Enclosure	Metal
Product Type	Managed Switch
Ports	24 x 10/100/1000BASE-T, 4 x 100/1000BASE-X SFP
MAC Address Table	8K
Jumbo Frame	9K Bytes
Operating Temperature	0°C to 50°C
Storage Temperature	-40°C to 70°C
Humidity	5% to 95% (non-condensing)
Installation	Rack-mountable
Dimensions	440 x 180 x 44 mm (W x D x H)
Weight	GS-4210-24UP4S: 2500g
