User’s Manual of GS-4210 Series
Figure 4-5-6 Edit Interface Setting Page Screenshot
The page includes the following fields:
Object Description
 Port
The switch port number of the logical port
 Interface VLAN Mode
Display the current interface VLAN mode
 PVID
Display the current PVID
 Accepted Frame Type
Display the current access frame type
 Ingress Filtering
Display the current ingress filtering
 Uplink
Display the current uplink mode
 TPID
Display the current TPID
125

Planet GS-4210 SERIES Specifications

General

Power Input	100-240VAC, 50/60Hz
Enclosure	Metal
Product Type	Managed Switch
Ports	24 x 10/100/1000BASE-T, 4 x 100/1000BASE-X SFP
MAC Address Table	8K
Jumbo Frame	9K Bytes
Operating Temperature	0°C to 50°C
Storage Temperature	-40°C to 70°C
Humidity	5% to 95% (non-condensing)
Installation	Rack-mountable
Dimensions	440 x 180 x 44 mm (W x D x H)
Weight	GS-4210-24UP4S: 2500g
