User’s Manual of GS-4210 Series
RSTP-Operation and MSTP-Operation.
 Configuration Name
Identifier used to identify the configuration currently being used.
 Configuration Revision
Identifier used to identify the configuration currently being used.
The values allowed are between 0 and 65535.
The default value is 0.
Buttons
: Click to apply changes.
Figure 4-6-5 STP Information Page Screenshot
The page includes the following fields:
Object Description
 STP
Display the current STP state
 BPDU Forward
Display the current BPDU forward mode
 Cost Method
Display the current cost method
 Force Version
Display the current force version
 Configuration Name
Display the current configuration name
 Configuration Revision
Display the current configuration revision
151

Planet GS-4210 SERIES Specifications

General

Power Input	100-240VAC, 50/60Hz
Enclosure	Metal
Product Type	Managed Switch
Ports	24 x 10/100/1000BASE-T, 4 x 100/1000BASE-X SFP
MAC Address Table	8K
Jumbo Frame	9K Bytes
Operating Temperature	0°C to 50°C
Storage Temperature	-40°C to 70°C
Humidity	5% to 95% (non-condensing)
Installation	Rack-mountable
Dimensions	440 x 180 x 44 mm (W x D x H)
Weight	GS-4210-24UP4S: 2500g
