Planet GS-4210 SERIES User Manual

User’s Manual of GS-4210 Series
 Tx Hold Count
The number of BPDU's a bridge port can send per second.
When exceeded, transmission of the next BPDU will be delayed. Valid values are
in the range 1 to 10 BPDU's per second.
 Hello Time
The time that controls the switch to send out the BPDU packet to check STP
current status.
Enter a value between 1 through 10.
Buttons
: Click to apply changes.
Figure 4-6-9 CIST Instance Information Page Screenshot
The page includes the following fields:
Object Description
 Priority
Display the current CIST priority
 Max Hop
Display the current Max. hop
 Forward Delay
Display the current forward delay
 Max Age
Display the current Max.Age
 Tx Hold Count
Display the current Tx hold count
 Hello Time
Display the current hello time
156

Planet GS-4210 SERIES Specifications

General

Power Input	100-240VAC, 50/60Hz
Enclosure	Metal
Product Type	Managed Switch
Ports	24 x 10/100/1000BASE-T, 4 x 100/1000BASE-X SFP
MAC Address Table	8K
Jumbo Frame	9K Bytes
Operating Temperature	0°C to 50°C
Storage Temperature	-40°C to 70°C
Humidity	5% to 95% (non-condensing)
Installation	Rack-mountable
Dimensions	440 x 180 x 44 mm (W x D x H)
Weight	GS-4210-24UP4S: 2500g
