Planet GS-4210 SERIES User Manual

User’s Manual of GS-4210 Series
 VLAN List
Display the current VLAN list
 VLAN Count
Display the current VLAN count
 Priority
Display the current MSTI priority
Figure 4-6-14 MST Instance Status Page Screenshot
The page includes the following fields:
Object Description
 MSTI ID
Display the MSTI ID.
 Regional Root Bridge
Display the current designated root bridge
 Internal Root Cost
Display the current internal root cost
 Designated Bridge
Display the current designated bridge
 Root Port
Display the current root port.
 Max Age
Display the current max. age.
 Forward Delay
Display the current forward delay.
 Remaining Hops
Display the current remaining hops.
 Last Topology Change
Display the current last topology change.
160

Planet GS-4210 SERIES Specifications

General

Power Input	100-240VAC, 50/60Hz
Enclosure	Metal
Product Type	Managed Switch
Ports	24 x 10/100/1000BASE-T, 4 x 100/1000BASE-X SFP
MAC Address Table	8K
Jumbo Frame	9K Bytes
Operating Temperature	0°C to 50°C
Storage Temperature	-40°C to 70°C
Humidity	5% to 95% (non-condensing)
Installation	Rack-mountable
Dimensions	440 x 180 x 44 mm (W x D x H)
Weight	GS-4210-24UP4S: 2500g
