User’s Manual of GS-4210 Series
GS-4210-24P4C / GS-4210-24PL4C
Product GS-4210-24P4C GS-4210-24PL4C
Hardware Specifications
Copper Ports 28 x 10/100/1000BASE-T RJ45 auto-MDI/MDI-X ports
SFP/mini-GBIC Slots
4 x 100/1000BASE-X SFP interfaces shared with Port-25 to Port-28.
Supports 100/1000Mbps dual mode and DDM
PoE Injector Port 24 ports with 802.3at / af PoE injector function with Port-1 to Port-24
Console 1 x RS-232-to-RJ45 serial port (115200, 8, N, 1)
Switch Architecture Store-and-Forward
Switch Fabric 56Gbps / non-blocking
Switch Throughput@64Bytes 41.67Mpps
Address Table 8K entries
Shared Data Buffer 4.1 megabits
Flow Control
IEEE 802.3x pause frame for full-duplex
Back pressure for half-duplex
Jumbo Frame
10K bytes
Reset Button
< 5 sec: System reboot
> 5 sec: Factory default
LED
PWR, SYS, LNK/ACT, PoE-in-Use, 1000, FAN 1 Alert, FAN 2 Alert, PoE PWR Alert
Smart Fan
2 3
Dimensions (W x D x H) 440 x 300 x 44.5 mm, 19-inch, 1U height
Weight 4.214kg 4.814kg
Power Requirements AC 100~240V, 50/60Hz, auto-sensing
ESD Protection 2KV DC
Power Consumption /
Dissipation
275 watts (max.) /
938.3 BTU
544 watts (max.) /
1856.2 BTU
Enclosure Metal
Power over Ethernet
PoE Standard IEEE 802.3af / 802.3at PoE / PSE
PoE Power Supply Type End-span
PoE Power Output Per Port 52V DC, 30.8 watts (max.)
Power Pin Assignment 1/2(+), 3/6(-)
PoE Power Budget
220 watts (max.) @ 25 degrees C
190 watts (max.) @ 50 degrees C
440 watts (max.) @ 25 degrees C
380 watts (max.) @ 50 degrees C
PoE Ability PD @ 9 watts 24 units
PoE Ability PD @ 15.4 watts 14 units 24 units
PoE Ability PD @ 30 watts 7 units 14 units
Layer 2 Functions
