Planet GS-4210 SERIES User Manual

User’s Manual of GS-4210 Series
 Server Priority
Set the server priority
 Dead Time
The Dead Time, which can be set to a number between 0 and 3600 seconds, is
the period during which the switch will not send new requests to a server that has
failed to respond to a previous request. This will stop the switch from continually
trying to contact a server that it has already determined as dead.
Setting the Dead Time to a value greater than 0 (zero) will enable this feature, but
only if more than one server has been configured.
 Usage Type
Set the usage type. The following modes are available:
 Login
 802.1X
 All
Buttons
: Click to add Radius server setting.
Figure 4-9-12 Login Authentication List Page Screenshot
The page includes the following fields:
Object Description
 IP Address
Display the current IP address
 Auth Port
Display the current auth port
 Acct Port
Display the current acct port
 Key
Display the current key
 Timeout
Display the current timeout
 Retries
Display the current retry times
 Priority
Display the current priority
 Dead Time
Display the current dead time
 Usage Type
Display the current usage type
 Modify
Click
to edit login authentication list parameter.
Click
to delete login authentication list entry.
226

Planet GS-4210 SERIES Specifications

General

Power Input	100-240VAC, 50/60Hz
Enclosure	Metal
Product Type	Managed Switch
Ports	24 x 10/100/1000BASE-T, 4 x 100/1000BASE-X SFP
MAC Address Table	8K
Jumbo Frame	9K Bytes
Operating Temperature	0°C to 50°C
Storage Temperature	-40°C to 70°C
Humidity	5% to 95% (non-condensing)
Installation	Rack-mountable
Dimensions	440 x 180 x 44 mm (W x D x H)
Weight	GS-4210-24UP4S: 2500g
