Planet GS-4210 SERIES User Manual

User’s Manual of GS-4210 Series
Object Description
 Server Definition
Set the server definition
 Server IP
Address of the TACACS+ server IP/name
 Server Port
Network (TCP) port of TACACS+ server used for authentication messages.
(Range: 1-65535; Default: 49)
 Server Key
The key- shared between the TACACS+ Authentication Server and the switch.
 Server Timeout
The number of seconds the switch waits for a reply from the server before it
resends the request.
 Server Priority
Set the server priority
Buttons
: Click to add Radius server setting.
Figure 4-9-15 Login Authentication List Page Screenshot
The page includes the following fields:
Object Description
 IP Address
Display the current IP address
 Port
Display the current port
 Key
Display the current key
 Timeout
Display the current timeout
 Retries
Display the current retry times
 Priority
Display the current priority
 Modify
Click
to edit login authentication list parameter
Click
to delete login authentication list entry
228

Planet GS-4210 SERIES Specifications

General

Power Input	100-240VAC, 50/60Hz
Enclosure	Metal
Product Type	Managed Switch
Ports	24 x 10/100/1000BASE-T, 4 x 100/1000BASE-X SFP
MAC Address Table	8K
Jumbo Frame	9K Bytes
Operating Temperature	0°C to 50°C
Storage Temperature	-40°C to 70°C
Humidity	5% to 95% (non-condensing)
Installation	Rack-mountable
Dimensions	440 x 180 x 44 mm (W x D x H)
Weight	GS-4210-24UP4S: 2500g
