Planet GS-4210 SERIES User Manual

User’s Manual of GS-4210 Series
 Management Method
Indicates the host can access the switch from
HTTP/HTTPs/telnet/SSH/SNMP/All interface that the host IP address matched
the entry.
 Action
An IP address can contain any combination of permit or deny rules.
(Default: Permit rules)Sets the access mode of the profile; either permit or
deny.
 Port
Select port for this drop down list
 IP-Source
Indicates the IP address for the access management entry
Buttons
: Click to apply changes.
Figure 4-9-30 Profile Rule Table Page Screenshot
The page includes the following fields:
Object Description
 Access Profile Name
Display the current access profile name
 Priority
Display the current priority
 Management Method
Display the current management method
 Action
Display the current action
 Port
Display the current port list
 Source IPv4
Display the current source IPv4 address
 Source IPv4 Mask
Display the current source IPv4 mask
 Source IPv6
Display the current source IPv6 address
 Source IPv6 Prefix
Display the current source IPv6 prefix
 Modify
Click
to edit profile rule parameter
Click
to delete profile rule entry
238

Planet GS-4210 SERIES Specifications

General

Power Input	100-240VAC, 50/60Hz
Enclosure	Metal
Product Type	Managed Switch
Ports	24 x 10/100/1000BASE-T, 4 x 100/1000BASE-X SFP
MAC Address Table	8K
Jumbo Frame	9K Bytes
Operating Temperature	0°C to 50°C
Storage Temperature	-40°C to 70°C
Humidity	5% to 95% (non-condensing)
Installation	Rack-mountable
Dimensions	440 x 180 x 44 mm (W x D x H)
Weight	GS-4210-24UP4S: 2500g
