User’s Manual of GS-4210 Series
Figure 4-9-35 DHCP Snooping VLAN Setting Page Screenshot
The page includes the following fields:
Object Description
 VLAN List
Indicates the ID of this particular VLAN.
 Status
Indicates the DHCP snooping mode operation. Possible modes are:
 Enabled: Enable DHCP snooping mode operation.
When enable DHCP snooping mode operation, the request
DHCP messages will be forwarded to trusted ports and only
allowed reply packets from trusted ports.
 Disabled: Disable DHCP snooping mode operation.
Buttons
: Click to apply changes.
Figure 4-9-36 DHCP Snooping VLAN Setting Page Screenshot
The page includes the following fields:
Object Description
 VLAN List
Display the current VLAN list
 Status
Display the current DHCP snooping status
243
