Planet GS-4210 SERIES User Manual

User’s Manual of GS-4210 Series
 Allow Untrusted
Select modes for this drop down list. The following modes are available:
 Drop
 Keep
 Replace
Buttons
: Click to apply changes.
Figure 4-9-47 Option82 Global Setting Page Screenshot
The page includes the following fields:
Object Description
 Port
The switch port number of the logical port
 Enable
Display the current status
 Allow Untrusted
Display the current untrusted mode
252

Planet GS-4210 SERIES Specifications

General

Power Input	100-240VAC, 50/60Hz
Enclosure	Metal
Product Type	Managed Switch
Ports	24 x 10/100/1000BASE-T, 4 x 100/1000BASE-X SFP
MAC Address Table	8K
Jumbo Frame	9K Bytes
Operating Temperature	0°C to 50°C
Storage Temperature	-40°C to 70°C
Humidity	5% to 95% (non-condensing)
Installation	Rack-mountable
Dimensions	440 x 180 x 44 mm (W x D x H)
Weight	GS-4210-24UP4S: 2500g
