Planet GS-4210 SERIES User Manual

User’s Manual of GS-4210 Series
Figure 4-9-61 IP Source Guard Port Setting Page Screenshot
The page includes the following fields:
Object Description
 Port
The switch port number of the logical port
 Status
Display the current status
 Verify Source
Display the current verify source
 Max Binding Entry
Display the current max binding entry
 Current Binding Entry
Display the current binding entry
262

Planet GS-4210 SERIES Specifications

General

Power Input	100-240VAC, 50/60Hz
Enclosure	Metal
Product Type	Managed Switch
Ports	24 x 10/100/1000BASE-T, 4 x 100/1000BASE-X SFP
MAC Address Table	8K
Jumbo Frame	9K Bytes
Operating Temperature	0°C to 50°C
Storage Temperature	-40°C to 70°C
Humidity	5% to 95% (non-condensing)
Installation	Rack-mountable
Dimensions	440 x 180 x 44 mm (W x D x H)
Weight	GS-4210-24UP4S: 2500g
