User’s Manual of GS-4210 Series
Figure 4-12-13 Port LLDP MED Configuration Page Screenshot
The page includes the following fields:
Object Description
 Interface
The switch port number of the logical port
 LLDP MED Status
Display the current LLDP MED status
 Active
Display the current active status
 Application
Display the current application
 Location
Display the current location
 Inventory
Display the current inventory
The MED Location Configuration and LLDP MED Port Location Table screens in Figure 4-12-14 & Figure 4-12-15 appear.
Figure 4-12-14 Port LLDP MED Configuration Page Screenshot
