User’s Manual of GS-4210 Series
 Delta: Calculate the difference between samples.
 Rising Threshold
Rising threshold value (0–2147483647)
 Falling Threshold
Falling threshold value (0–2147483647)
 Rising Event
Event to fire when the rising threshold is crossed
 Falling Event
Event to fire when the falling threshold is crossed
 Owner
Specify an owner for the alarm
Buttons
: Click to apply changes.
Figure 4-14-6: RMON Alarm Status Page Screenshot
The page includes the following fields:
Object Description
 Index
Indicates the index of Alarm control entry
 Sample Port
Display the current sample port
 Sample Variable
Display the current sample variable
 Sample Interval
Display the current interval
 Sample Type
Display the current sample type
 Rising Threshold
Display the current rising threshold
 Falling Threshold
Display the current falling threshold
 Rising Event
Display the current rising event
 Falling Event
Display the current falling event
 Owner
Display the current owner
 Action
Click
to delete RMON alarm entry
327

Planet GS-4210 SERIES Specifications

General

Power Input	100-240VAC, 50/60Hz
Enclosure	Metal
Product Type	Managed Switch
Ports	24 x 10/100/1000BASE-T, 4 x 100/1000BASE-X SFP
MAC Address Table	8K
Jumbo Frame	9K Bytes
Operating Temperature	0°C to 50°C
Storage Temperature	-40°C to 70°C
Humidity	5% to 95% (non-condensing)
Installation	Rack-mountable
Dimensions	440 x 180 x 44 mm (W x D x H)
Weight	GS-4210-24UP4S: 2500g
