Planet GS-4210 SERIES User Manual

User’s Manual of GS-4210 Series
This
section allows the user to inspect and configure the current PoE port settings
as Figure 4-16-3 shows.
Figure 4-16-3: Power over Ethernet Configuration Screenshot
The page includes the following fields:
Object Description
 PoE Mode
There are three modes for PoE mode.
 Enable: enable PoE function..
 Disable: disable PoE function.
 Schedule: enable PoE function in schedule mode.
 Schedule
Indicates the scheduled profile mode. Possible profiles are:
 Profile1
 Profile2
 Profile3
 Profile4
 AF/AT Mode
Allows user to select 802.3at or 802.3af compatibility mode. The default value is
802.3at mode.
This function will affect PoE power reservation in Classification power limit mode
334

Planet GS-4210 SERIES Specifications

General

Power Input	100-240VAC, 50/60Hz
Enclosure	Metal
Product Type	Managed Switch
Ports	24 x 10/100/1000BASE-T, 4 x 100/1000BASE-X SFP
MAC Address Table	8K
Jumbo Frame	9K Bytes
Operating Temperature	0°C to 50°C
Storage Temperature	-40°C to 70°C
Humidity	5% to 95% (non-condensing)
Installation	Rack-mountable
Dimensions	440 x 180 x 44 mm (W x D x H)
Weight	GS-4210-24UP4S: 2500g
